Symptom
A radard chart created in the Online Report Designer does not display data as expected.
Environment
SuccessFactors Online Report Designer
Reproducing the Issue
- Create a new report in the Online Report Designer
- Add a blank page to the report and edit it.
- Add a new Chart component to the page.
Example: Chart view based on published data. - Select the componet and click 'Edit Query'.
- Choose the appropriate data source.
- Once back in the page, set 'Chart Type' to 'Radar'.
- The chart displays data in a wierd manner.
Actual result for the following example dataset:
Category 1 2 3 4 5 6 7 8 9 10 11 12 Manager Review 2 2 4 4 2 2 2 2 2 2 2 2 Self Review 3 3 3 3 3 3 3 3 3 3 3 3
Category | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
Manager Review | 2 | 2 | 4 | 4 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Self Review | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
Cause
'Series Ordering' for the chart has been set to 'Ascending’ or ‘Descending’
However, due to their design logic, Radar charts do not support series ordering customization * and hence the strange behavior.
*Note: This limitation with radar chart applies to all charting / reporting tools and not just to SuccessFactors.
Resolution
Change Series Ordering to ‘Native’ through the following steps:
- Select the Chart component.
- Click ‘Edit Formatting’.
- Under the ‘Chart’ tab, set ‘Series Ordering’ to ‘Native’.
Keywords
Radar Chart Spider Chart , KBA , LOD-SF-ANA-ORD , Online Report Designer , Problem
Product
SAP SuccessFactors HCM Core 1702
